Hcvac Super Quality Automatic Uv Coating Machine

Magnetron sputtering is a plasma coating process whereby sputtering material is ejected due to bombardment of ions to the target surface. The vacuum chamber of the PVD coating machine is filled with an inert gas, such as argon. By applying a high voltage, a glow discharge is created, resulting in acceleration of ions to the target surface and a plasma coating. The argon-ions will eject sputtering materials from the target surface (sputtering), resulting in a sputtered coating layer on the products in front of the target. Magnetron sputtering technology is characterized by.

Product Details

Quick Details

Description

Magnetron Sputtering Coating

Plasma coating

Magnetron sputtering is a plasma coating process whereby sputtering material is ejected due to bombardment of ions to the target surface. The vacuum chamber of the PVD coating machine is filled with an inert gas, such as argon. By applying a high voltage, a glow discharge is created, resulting in acceleration of ions to the target surface and a plasma coating. The argon-ions will eject sputtering materials from the target surface (sputtering), resulting in a sputtered coating layer on the products in front of the target. Magnetron sputtering technology is characterized by:

A water-cooled target, so little radiation heat is generated

Almost any metallic target material can be sputtered without decomposition

Non-conductive materials can be sputtered by using radio frequency (RF)

or medium frequency (MF) power

Oxide coatings can be sputtered (reactive sputtering)

Excellent layer uniformity

Very smooth sputtered coatings (no droplets)

Cathodes (of up to 2 meter long) can be put in any position, therefore high

flexibility of sputtering equipment design



HCVAC decorative PVD films are routinely used as a replacement for electroplated chrome. They can be applied directly over almost any substrate material and can be deposited in a wide variety of colors. The process parameters to deposit each color are stored in software recipes with different process steps. Once the coating process has started, all of the relevant process parameters are continuously monitored and controlled by the on-board computer software.



Features

Characteristic: reasonable structure, even film, good-quality film forming, quick pumping speed, the cycle of short, high efficiency and easy operation, low energy consumption and performance advantages of stability.



Machine Features:

 -High reliability

-High productivity and flexibility



-Consistently brilliant end product quality

-Full automation capability

-Excellent coating flexibility

-Long lifetime and fast target exchange

-Flexible system configuration

-High speed coating and best PVD homogeneity



APPlication

Applied industry: Widely used in automotive plastic parts, audio and varinous small appliances, computers, clocks and watches, toys cell phones reflective Cup, cosmetics toys tableware sanitary shoe heel, ABS, PS, PP, PC, PVC, PET, nylon,metal, Boli, glass, ceramics, TPU, etc.



Electroplating effects: general electroplating-face, dumb-(semi-mute, all dumb), the electroplating process wrinkles, wiredrawing,raindrop ect.



Coating: Can get any single steady metal coating on plastic,like: chrome,stainless steel,copper,nickle,Titanium and others, the machine can match with painting line to get best quality



TECHNICAL DATA

Mode

JT-1214

JT-1416

JT-1618

JT-1820

Dimension (D*H)

1200*1400mm

1400*1600mm

1600*1800mm

1800*2000mm

Film type

Semitransparent film, non-conducting film, gold, silver, red, blue, green, purple, seven color, etc

Power source

Thermal evaporation power, ion bombard power, RF power

Vacuum chamber structure

Vertical double/single door, horizontal single door, pump system postposition

Ultimate vacuum

8.0*10-4Pa

Vacuum system

Diffusion pump +Roots pump +Mechanical pump +Holding pump

Pump time

Pump from atmosphere to 5.0*10-2,<=6 minutes

Workpiece motion mode

Public rotation/ Frequency control

Control mode

Manual/Automatic all in one mode, Touch screen + PLC

Remark

We can design the dimension of the equipment according to customer’s special technique requirement.
