Disc suspension porcelain insulators

Disc suspension porcelain insulators are mainly used on high-voltage overhead transmission and distribution lines to support and insulate conductors. The normal type disc suspension porcelain insulators include standard type and large creepage distance type insulators. These insulators are widely used in clean areas and light pollution areas. Please contact us! Email:

Product Details

Quick Details

Description

Skype: liujingmec
liujing@mec.com.cn

Disc suspension porcelain insulators are mainly used on high-voltage overhead transmission and distribution lines to support and insulate conductors. The normal type disc suspension porcelain insulators include standard type and large creepage distance type insulators. These insulators are widely used in clean areas and light pollution areas.
Type







Class






IEC
Unite spacing


(H)


mm
Nominal diameter


(D)


mm
Nominal
creepage
distance

(L)


mm
Coupling size






Rated E&M failing load



kN
Routine tension load




kN
Impact failing load




N. m
Power-frequency withstand voltage
Dry lightning impulse withstand voltage


kV
Power-frequency puncture voltage





kV
Radio-interference voltage
Unite mass






kg
Wet



kV
Dry



kV
Test voltage to ground
kV
Max. RIV at 1 MHz

μV
Xp1-40
U40B
110
175
190
11
40
20
5
30
55
75
90
7.5
50
2.4
Xp-40c
U40C
140
190
200
11C
40
20
5
30
55
75
90
7.5
50
2.7
Xp-70
U70BL
146
255
295/340
16
70
35
6
40
70
100
110
10
50
4.6/5.3
Xp-70C
U70C
146
255
295
16C
70
35
6
40
70
100
110
10
50
4.8
XP1-70
U70BS
127
255
295/320
16
70
35
6
40
70
100
110
10
50
4.6/4.8
Xp4-70
U70BL
146
270
330
16
70
35
6
40
70
100
110
10
50
5.00
Xp5-70
U70BL
146
200
210
16
70
35
6
30
50
80
110
10
50
3.7
Xp-80
U80BM/L
140/146
255
295
16
80
40
6
40
70
100
110
10
50
4.9
Xp-100
U100BL
146
255
295/320
16
100
50
7
40
70
100
110
10
50
5.7/6.0
Xp3-100
U100BL
146
280
340
16
100
50
7
40
70
100
110
10
50
6.6
