Clamping Force Testing Machine

This machine is designed to measure the deflections of product packages and protective capacity of packages for product when suffering level pressure in the process of transportation and storage to improve the quality of product package.

Product Details

Quick Details

Description

Quick Details

Place of Origin: Guangdong, China (Mainland)

Brand Name: Haida

Model Number: HD-A534

Power: Electronic, 220v/ 60Hz

Usage: Universal Testing Machine

Maximum specimen weight: 600kg

Clamping plate size: Height 48inch* depth 48inch

Clamping plate adjustable height: 0~1000mm

Clamping plate adjustable width: 200~2000mm

Base plate dimension: 2200 *2100mm

Motor: Panasonic Servo Motor

Accuracy: within ±5%

Clamping force rate: 0.25-2.5mm/sec (according ISTA 6- SAMS CLUB)

Calibration accuracy: ±1% F.S

Packaging & Delivery

Packaging Details:

Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

Delivery Detail:

within 15 days after receiving deposit

Features:Clamping Force Testing Machine

This machine is designed to measure the deflections of product packages and protective capacity of packages for product when suffering level pressure in the process of transportation and storage to improve the quality of product package.



Design Criteria: Clamping Force Testing Machine

ASTM D642\ ISTA 6- SAMS CLUB\ ISTA 3J



Main parameter: Clamping Force Testing Machine

Specimen shape

Parallelepiped transport package

Maximum specimen weight

600kg

Clamping pressure force

According to the transport diagram on the test sample, the operator can add 400-3000Lb (adjustable) pressure force on the corresponding surface.

Clamping plate size

Height 48inch X depth 48inch

Clamping plate adjustable height

0~1000mm

Clamping plate adjustable width

200~2000mm

Base plate dimension

2200 X 2100mm

Motor

Panasonic Servo Motor

Accuracy

within ±5%

Clamping plate requirement

Make the two clamping boards flat and non-deform under work condition (2000 Pounds) and make clamping boards’ parallel and clamping board and land vertical. Clamping board is thicker than 25mm.

Clamping force rate

0.25-2.5mm/sec (according ISTA 6- SAMS CLUB)

Force corrector

It displays force value and is used to calibrate clamping force.

Calibration accuracy

±1% F.S

Device width

Less than 2.5m

Weight

approx. 2000kg

Power

220v/ 60Hz

Controller:

touch screen type, which can control & display the speed and force

Function

the clamp can be up and down

Control

Computer controlled type



Company Profile

Haida International Equipment Co., Ltd, which headquartered in Dongguan. since 2004, we have  professional manufacturing experience in testing equipment industry. Haida Mission is become one of the most important leaders in the precision testing instrument industry.

Our company Vision "Quality Comes From Precision, Quality Creates the Future". Haida staff focous on  each piece of work well for our customers. At the same time, Haida  explore actively and established good business relationship with many international enterprises(EG: Ikea, Nitori, SGS,Intertek......) with their sincererity.

Haida International Equipment Co., Ltd  mainly focus on research, manufacture and sales in Paper package test instrument, Tensile testing instrument, Printing testing instrument, Adhesive tape testing instrument, Bags & luggage test instrument, Environmental Test Instrument,Furniture testing instrument, Hairdressing product testing instrument, Plastic rubber Testing instrument, Baby products testing instrument, toy testing instrument, Clothing, shoes testing instrument and so on all kinds of national standard, tailor-made precision apparatus. The products meet UL, ASTM, JIS, GB, ISO, TAPPI, EN, BS...and other domestic and international standards.

Haida International Equipment Co, Ltd looks forward to cooperate with customer all over the world.

office

factroy
