CNC lathe machine
Specification
WXC30S
RAW


   MATERIALS
Diameter Range(mm)
Φ6˜Φ32
Raw Material Length(mm)
≥1400
Tensile Strength (M pa)
≤1100
Surface Hardness
≤HB320
Curvature(mm/m)
≤1.5
Diameter Tolerance
according to GB 702-88 second group
Roundness
≤50% of the diameter tolerance
Surface Roughness(Ra)
≤25˜50um
FINISHED

GOODS
Diameter Range
Φ5.5˜Φ30
Unilateral Cutting Depth(mm)
0.2-1
Diameter Tolerance
≤IT9(standard tolerance grade)
Surface Roughness(Ra)
≤6.3μm
Roundness
≤0.03
Feeding Cutting Speed(m/min)
1.0~10.0(for continuous chips and high strength and hardness should reduce the speed
Cutter Head Rotational Speed(rpm)
450˜1250
Main Machine Motor Power(KW)
45 (4 Poles)
Auxiliary Machine Motor Power(KW)
4(feeding part)+0.55((discharging part) 4 Poles
Main Machine Outline Dimensions
(Length*Width*Height) m
2.5mX2.2mX1.5m (for your reference)
Full Set Machine Outline Dimensions
(including auxiliary machine)
(Length*Width*Height) m
12.5mX2.2mX1.5m (for your reference)
Main Machine Weight
(including auxiliary weight)(T)
3.5(6.0)
Total Capacity (KW)
56
Compressed Air Source(user prepare by themselves)
0.5~0.8MPa,1.8m3/min,more than 0.8 m3 gasholder, two-stage oil-water separator and compressed air freezing drier



Company Profile

Haige Machine Tools Co., Ltd. is a manufacturer of straightening machines and centerless turning machines with well-equipped testing equipment and strong technical force.

With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in Bars of various materials, wire processing and other industries.

Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.

We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
