• CNC lathe machine -CK0625AD

CNC lathe machine -CK0625AD

Characteristic: 1 ractical.convenient operation, high precision machining 2 the operating system simple , reliable performance Please contact:naijiaxin11@yeah.net

Product Details

Quick Details

Description

NC0625CNC lathes
Technical Parameters / Configuration

Item
Specification
Parameter
1
Controlled and linkage axis numbers
2 axes (X, Z axis)
2
Maximum length of processing parts
200mm
3
      Minimum setting unit
0. 001mm
4
Smallest movement unit
    X axis:0.0005mm  Z axis :0. 001mm
5
Tool changer placing mode
Row
6
Cutting speed
1~ 6000 mm/min
7
Spindle
Mechanical spindle
8
Control System
 Taiwan SYNTEC
9

Median knife can be controlled

8station
10
 Rated Voltage
Three phase AC 380V
11
Rated Frequency
50 Hz
12
Maximum input power
3 KW
13
X axis Maximum travel
          150 mm  (Volume diameter  300mm  )
14
Z axis Maximum travel
180mm
15
Maximum diameter of processing the bar
25mm
16
X, Z axis rapid feed rate
22000 mm/min,20000mm/min(X,Z axis)
17
Spindle motor power
2.2KW
18
Spindle highest speed
5000rpm
19
 Input compressed air pressure
0.4~0.6MPa
20
Control System
Taiwan SYNTEC
21
Servo Motor
    Panasonic / Taiwan Delta Servo Motor
22
Guide Rail
Taiwan HIWIN Linear Guides
23
Inverter
INVT
24
Encoder
REP
25
Machine Net Weight(kg)
About 1200



Company Profile

Tai'an Haina Spindle Science & Technology Co., Ltd., located at the foot of famous Mount Tai, is a high-tech enterprise specialized in producing high-speed spindles. We have excellent equipment, advanced technologies and strong capacity in spindle design, development and production. The HNZ series of high-speed electric spindle features high precision, high rigidity, high efficiency, high power, and low noise. The speed reaches 1,000-120,000 revolutions per minute, with frequency control. The spindles can be extensively used in high-speed cylindrical grinding, precision engraving, CNC drilling, milling and other equipment, and sell well in both domestic and overseas markets.
