• CNC VERTICAL MACHINING CENTER VMC 21100

CNC VERTICAL MACHINING CENTER VMC 21100

CNC VERTICAL MACHINING CENTER VMC 21100: 1.Model :VMC 21100 2.Layout forms :Vertical, VMC machine 3.Brand: KAFO Please contact:zhuxiaochen124@126.com

Product Details

Quick Details

Description

CNC Vertical Machining center VMC 21100 Specifications:

Items Unit Specifications
Table
Table size mm 2400 × 1000
Table Max.load kg 3000
Spindle nose to table mm 250-1040
Spindle center to Z axis mm 1042
Travel
X axis mm 2150
Y axis mm 1000
Z axis mm 790
Spindle
Spindle motor (30 minutes) kw AC15/18.5
Spindle speed rpm 6000
Feed rate
X axis m/min 20
Y axis m/min 20
Z axis m/min 12
Positioning accuracy
X axis mm 0.004/300
Y axis mm 0.004/300
Z axis mm 0.004/300
Repeatability accuracy
X axis mm ±0.003
Y axis mm ±0.003
Z axis mm ±0.003
Servo motor
X axis kw 7
Y axis kw 7
Z axis kw 7
Dimensions
Weight kg 18500
Height mm 3510
Length×Width mm 4250× 5900



Company Profile

We are a investment enterprises of cross-sectoral, trans-regional, with modern concept and investment diversification, respectively located in Beijing, Zhejiang, Jiangsu, Yunnan and so on, developing CNC machine , software, logistics and other industries
Machinery-HHT, superb technical core manufacture for 20 years in TaiWan, possessing the most advanced and the most sophisticated heavy machinery equipment. THE producing machine being Imported from Spain and Italy: CNC Gantry five face equipment , CNC horizontal machining center, CNC five surface slideway grinding machine , CNC horizontal boring and milling machine with double table, and sophisticated testing equipment,all of them are great pieces in CNC machine industry products. Large-scale R & D team and customer service technology group, We can have the installation and commissioning to every country and 24 hour video guide.
The main production: CNC vertical machining center, CNC horizontal machining centers, CNC lathes, Gantry CNC machining center, CNC drilling and tapping machine, CNC lathing and milling machine center. The main customer base for precision mold industry, auto industry, the electronic communications industry, processing precision parts industry , aerospace industry and so on.
JIANHAI Group in accordance with "Lawfully operate, equality and voluntariness, safe and steady, market-oriented operation" management philosophy.Relying on Group's extensive investment and financing channels, fully integrated resources advantage, professional advantage. Always adhere to the market as the guidance, resource integration, capital operation as the means, combined with many investment ways,make the group develop repidly !
