  • CNC Grinding machine GXMK 1320A

CNC Grinding machine GXMK 1320A

1, CE Certificare 2, use the NSK bearing and SIMENS controller 3, Schneider breaker 4, Quality change the world Please contact us:zhangmimin122@126.com

Product Details

Quick Details

Description

The usual brand-name accessories:
   1) precision bearing NSK, imported from Japan;
  2) Famous brand auto centralized lubricating system;
  4) high-torque spindle motor of German techniques;
  4) famous brand encoder;
   5) famous brand ball-screw;
   6) low-voltage apparatus of Siemens and France Schneider;
   7) domestic brand-name machine tool accessories;
   8)the famous brand lighting and cooling system;
   9)Famous brand Hand - held electronic pulse wheel.(this is for the longth of the machine 1500 and 2000)
Optional NC system of famous brand:
 1) Siemens 802C servo
 2) Siemens 802D SL servo
3) Japan FANUC 0i-mate-TD servo
4)Guangzhou NC GSK980TDb servo


CNC Grinding machine with communication fibe-optical pole GXMK 1320A

technical parameters

GXMK 1320A

max. swing over bed
(mm)

630

width of the bed(mm)

550

max. swing over
crossslide (mm)

330

spindle taper

ME 202/1:50

spindle bore (mm)

200


spindle speed(r/min)

8.5, 13, 17, 26/33, 50, 65, 84/143, 217, 285,  432

three-jaw chuck (mm)

K11-500C

Bistrique motor power

2.2 KW/50Hz

main motor power (KW)

7.5/11KW/50Hz

Distance between unionchucks

1600

Chuck OD/ID

500 / 200

Z
axis

max. travel
(mm)

1400

travel speed
(m/min)

4~6

min. travel unit
(mm)

0.001

repeatability
accuracy(mm)

0.025

X
axis

max. travel
(mm)

380

travel speed
(m/min)

3~5

min. travel unit (mm)

0.001

repeatability
accuracy (mm)

0.016

overall dimensions
(L×W×H) (mm)

4200×2000×1900

gross\wet weight
(ton)

5.8/5.6



Company Profile

   "Quality Changes the World; Build Up a Brand Name; Make a Name Brand" is our goal.

    Our company is dedicated to the research and development, production and sale of CNC Machine tools. The registered capital of our company is RMB50,000,000; the total floor space is 93000 square meters; the building area is 80000 square meters.

    Our company has carried out ISO9001:2008 Quality Management System and cooperated with major academies regularly to develop different series of CNC machine tools. Our firm has got many national patents and has been awarded the honors of "High and New Tech Enterprise" and "Sincere Enterprise".

    In recent years, adhering to the mission of "Technology, Innovation, Service, Development", our company has constantly enhanced technology research and development and explored the market by researching and producing various series of high-end and new products. Our senior engineers and senior mechanism are the reliable guarantee for the quality products. Sticking to the idea of "quality is the lifeline", our company has formed perfect after-sales service systems. Relying on excellent quality and after-sales service, our products sell well all over the country and gain trust and support from customers.

Our products:
CNC Lathes:
CK6130H , CK6132H, CK6136, CK6136H, CK6140H, CK6140B, CK6140B3H, CK6150B, CK6150B3H, CJK6163, CJK6163H3, CK6163A, CK6163A3H, CK6180A, CK6180A3H, CK61100, CK61100A3H, CK61125A, CK61125A3H, CK61125B, CK61125B3H, CK61160B and CK61160B3H

Length of the Work Piece: 500mm, 750mm, 1m, 1.5m, 2m, 3m, 5m and 8m

CNC Pipe-Threading Lathes:
QK1313a, QK1313b, QK1320A, QK1327A, QK1335B and QK1344B

CNC Heavy-Duty Vertical Lathes:
CK5225, CK5234, CK5240, CK5250, CK5263, CK5280, CK52100 and CK52125
