• CIL-SP-A-A(B)-2 Full-automatic toilet paper(towel paper) production line

CIL-SP-A-A(B)-2 Full-automatic toilet paper(towel paper) production line

CIL-SP-A-A(B)-2 Full-automatic toilet paper(towel paper) production line is full-automatic production line, which composed of 1 set of CIL-SP-B(A)-2 Full-automatic high-speed rewinding and perforated toilet paper(towel paper ) machine (it can be 2 sets according to requirement), 1 set of CIL-SP-280 cutting machine, 1 set of CIL-SP-398-3 multi-rolls packing machine and convey belts.

Product Details

Quick Details Parameter

Width of raw material: : 1200mm--2750mm
Dia.of raw material: : Up to Φ1500mm
Core inside diameter of raw material: : Φ76.2mm
Machine speed: : 0-250m/min
Operating speed: : 0-200m/min
Installed power: : 7.5Kw~15Kw

Description

CIL-SP-A-A(B)-2 Full-automatic toilet paper(towel paper) production line
CIL-SP-A-A-2 Full-automatic toilet paper production line is full-automatic production line, which composed of 1 set of CIL-SP-B(A)-2 Full-automatic high-speed rewinding and perforated toilet paper(towel paper ) machine (it can be 2 sets according to requirement), 1 set of CIL-SP-280 cutting machine, 1 set of CIL-SP-398-3 multi-rolls packing machine and convey belts.

A、The max. width of jumbo roll can up to 2750mm. Perforation distance can be adjusted to satisfy any length need. As required, the equipment can have one or two embossing device. Equip weight pneumatic loading of jumbo roll system. According to requirement, the equipment can have 3 jumbo roll holder.
B、CIL-SP-A-A(B)-2 Economical rewinding production line will automatically change core and unload the finished products, and automatically trim and seal the tails of the logs, leaving a tail about 20mm. Automatically convey the logs into conveyer belt, and carry into CIL-SP-280 to cut into the length required. Through the conveyer belt come into CIL-SP-398 -3for package.
C、The complete production line controlled by PLC. Main motor can be controlled by variable frequency speed control.

Technical parameter

Width of raw material
1200mm--2750mm
Dia.of raw material
Up to Φ1500mm
Core inside diameter of raw material
Φ76.2mm
Machine speed
0-250m/min (depending on
model)
Operating speed
 0-200m/min
Outside diameter of finished roll
Toilet paper :Φ80-150mm
Outside diameter of finished roll
Kitchen towel:Φ80-150mm
Perforation pitch
Variable, any size needed
Inner diameter of core of finished product
Φ25-80mm
Raw material for toilet paper
1or 2 layer,14-20g
Raw material for kitchen towel
1 layer, 30-45g
Installed power
7.5Kw~15Kw

CIL-SP-A-A(B)-2 Full-automatic toilet paper(towel paper) production line CIL-SP-A-A-2 Full-automatic toilet paper production line is full-automatic production line, which composed of 1 set of CIL-SP-B(A)-2 Full-automatic high-speed rewinding and perforated toilet paper(towel paper ) machine (it can be 2 sets according to requirement), 1 set of CIL-SP-280 cutting machine, 1 set of CIL-SP-398-3 multi-rolls packing machine and convey belts.   A、The max. width of jumbo roll can up to 2750mm. Perforation distance can be adjusted to satisfy any length need. As required, the equipment can have one or two embossing device. Equip weight pneumatic loading of jumbo roll system. According to requirement, the equipment can have 3 jumbo roll holder. B、CIL-SP-A-A(B)-2 Economical rewinding production line will automatically change core and unload the finished products, and automatically trim and seal the tails of the logs, leaving a tail about 20mm. Automatically convey the logs into conveyer belt, and carry into CIL-SP-280 to cut into the length required. Through the conveyer belt come into CIL-SP-398 -3for package. C、The complete production line controlled by PLC. Main motor can be controlled by variable frequency speed control.   Technical parameter
