BGA Rework Station

Adopted with Linear slider, so all the three axles (X, Y, and Z) can do fine tuning and quick orientation with perfect positioning accuracy and speedily maneuverability

Product Details

Quick Details

Description

Specification and Feature:

1.Adopted with Linear slider, so all the three axles (X, Y, and Z) can do fine tuning and quick orientation with perfect positioning accuracy and speedily maneuverability

2.Equipped with touch panel interface and PLC controlling to ensure it work stably and reliably. And it can storage multiple temperature profiling data of users. With password protection and modification function while power on. The temperature profiles will be displayed on the touch screen

3.Three temperature zones to heat up independently, hot air heat up between up and down zones, IR heat in the bottom, temperature precise control is in±3℃.The upper temperature zone can be moved freely according to needs, the second zone can be adjusted up and down. The top and bottom heaters can be set several segments control at the same time. IR heating zone can be adjusted output power in the light of operation requirements.

4.The hot air nozzle can be rotated in 360 degree, the IR heater in the bottom can heat up the PCB board uniformly.

5.High accuracy K-type thermocouple closed-loop controlling. It can test temperature accurately through external temperature measurement interface, PCB board positioned by closed V-shape slot. The flexible and convenient universal jigs can prevent any damage or PCB deformation as well as it is suitable for all size of BGA package.

6.Large power fan to cool down the PCB quickly. The built-in vacuum pump and external vacuum nozzle is able to take BGA chips out easily.

7.Having alarm prompt function after welding is done, specially added early warning function for convenient operation.




BGA Rework Station

Company Profile

Shenzhen Jaguar Automation is professional in manufacturing wave soldering machine and reflow oven,besides both two kinds of products, we also engaged in offering SMT conveyor, pick and place machine, LED equipments, PCB loader and unloader, screen printer and other SMT machines.
Our services, we devote to serve customers and meet all of their diversified requirments with stable technical level, innovative design concept, precise manufacturing process, reasonable price and customer first after-sales system.
JAGUAR has been committed to develop to lead-free machine and manufacture lead-free electronic devices since foundation. At present, we have researched and developed 4 sorts of environmental friendly reflow oven, there are A series, M series, F series and R series. What's more, we have also develop wave soldering machine, for example, the econimic wave solder, top lead free wave solder and high-end of large size wave solder. All of our machines are not only used wildly in electronic circuit, LED industry, instruments and apparatuses, but also in household appliances, such as washing machine, microwave, television ect.
