Auto screw driving machine for communication filter

This XYZ screw driving machine is designed special for communication filters which have the presence of locking screw and the quantity demands for high yield.

Product Details

Quick Details

Description

XYZ screw driving machine (PLC control)

 This XYZ screw driving machine is designed special for communication filters which have the presence of locking screw and the quantity demands for high yield. The machine can be set to any number of locations and coordinates a variety of products that can accurately complete the moving coordinate between the linear modules and servo motors. The equipment controlled by PLC program control panel with touch screen operation. Locking devices the torque error are ± 10%. Locking Screw part of the slide can be determined, floating locks, missing locks, slick and other undesirable characteristics.

2.     Mainly Parameter

Efficiency1piece/2 second

Power supply220V AC  50HZ

Air supply0.6MP

Warranty: 1 year

Production period: 45 days

Rated power: 50 Hz

Theoretical service life of 5-10 years

Dimensions: 1200 * 1200 * 1800

Weight: 300kg

3.      Technical Parameters

Module number: XYZ 3-axis

Modular drive mode: servo motor + ball screw

Module orientation: Linear Guides

Product coordinate storage: 500 kinds

Defective check: CCD imaging system (optional)

Coordinate origin control: mechanical origin and product origin

Safety Control: Safety light curtains, emergency stop switch

Fault indication: alarm sounds and fault indicator, failure to inform the content of the display .

Locking bad instructions and troubleshooting: bad inform the specific location of the lock screw and artificial password protection equipment continue to operate.

Product Positioning: fixed two sides, in addition to other sides simultaneously clamping



Equipment operating modes: adjust mode, manual mode, semi-automatic mode  and automatic mode.

I / O Check: All I / O are displayed on the screen, each output can be single-action

Send screw Detection: For each of the sub-feed screws for check.

Different Screw Replacement: Replacing screw feeder and beak.

Replace time: less than 10 minutes (including the replacement of the coordinates, screw feeder and beak)
