API SPEC 7K HYDRAULIC TUBING TONG

1. API Standard.
2. Professional.
3. Certificated by Customers.
4. Responsibility.

Product Details

Quick Details Parameter

Place of Origin : Panjin China (Mainland)
Brand Name : Tianyi
Model Number : S-HTQ
Type : API SPEC 7K HYDRAULIC TUBING
Machine Type : Drilling Equipment
Certification : API
Material : Carbon Steel
Processing Type : Casting
Use : Well Drilling
POWER TONG : API SPEC 7K HYDRAULIC TUBING TONG

Description

1.Medium: oil, gas.
Model TQ178-16 TQ340-20A TQ340-35 TQ178-16A TQ340-35A TQ508-70Y
Size range mm 101.6-178 101.6-340 139.7-340 101.6-178 101.6-340 244.5-508
in 4"-7" 4-133/8 51/2-133/8 4"-7" 4-133/8 1995/8/20
Hydraulic system pressure rating Mpa 18 16 18 18 18 20
Psi 2610 2320 2610 2610 2610 2900
Hydraulic system flow rating L/min 114 114 114 114 114 140-220
gpm 30.1 30.1 30.1 30.1 30.1 36.9-58.1
Max.
torque
kN.m 2.4-3 3.7 2.5-3 2.4-3 4.0-5.0 8.4-10.7
ft.ibf 1770-2200 2730 1844-2200 1770-2200 2950-3680 6195-7891.25
kN.m / / 6.0-7.5 / / /
ft.ibf 4420-5530
kN.m 16 20 35 15-18 27-30 48.9-70
ft.ibf 11800 14750 25800 11060-13280 19900-22120 36063.75-51625
RPM rpm 54-97 50-80 60-86 54-79 80-98 30.5-48
rpm     21-30
rpm 9-13.1 6 ~ 14 2.6-5.3 8.5-12 12 ~ 16 4.6-7.3
Overall dimensions mm 1540* 1520* 1540* 1500* 1560* 2080*
760*740 850*670 900*860 760*680 900*850 1280*760
in 61*30*29 60*34*26 61*36*34 59*30*27 61*35*33.5 82*50*30
Weight Kg 580 560 780 570 780 1550
Ib 1280 1234 1720 1250 1720 3420
