• 350W Electric Boba Tea Cup Sealer Sealing Machine

350W Electric Boba Tea Cup Sealer Sealing Machine

Power, turn the power switch, indicator lights, the thermostat is set to a predetermined temperature, when the green heating indicator light. When the hot plate reaches a predetermined temperature, the red indicator light is constant

Product Details

Quick Details Parameter

Type : Capping Machine
Condition : New
Application : Beverage
Driven Type : Electric
Automatic Grade : Automatic
Voltage : 220V or 110V
Power : 350W
Packaging Type : Cartons
Packaging Material : Paper
Place of Origin : Guangdong, China (Mainland)
Brand Name : ETON
Model Number : ET-A9
Dimension(L*W*H) : 230X320X500mm
Weight : 25kg
Certification : CE
Item : Cup Sealer Sealing Machine
sealing machine : cup sealer
Hot searching : Cup Sealer Sealing Machine
Filling Machine : cup sealer
Packaging Line : sealing machine
Apperance : Modern
Price : Factory price
Market : Worldwide

Description

Packaging & Delivery

Packaging Details: Carton for Cup Sealing Machine
Delivery Detail: 15 days after receipt the payment





Recommend Products





350W Electric Boba Tea Cup Sealer Sealing Machine

Product Show





Basic parameters of products

Name:

Cup Sealer Sealing Machine

Brands:

ETON

Model:

ET-A9

Size:

230X320X500mm

Power:

 220V / 110V

Frequency

50Hz

Output:

350W

 Out Put:

300~400cup/h

Packaging:

Carton

MOQ:

100



Product Introduction



Through film:
1. Get the film to be confirmed film winding direction, counterclockwise to identify, and put the rod fixed film. (Turn off the power when wearing film)
2. Note whether the film around the splints and film closely, if you can not closely integrated utility knife will need to use film paper tube inside of the bevel cut again into.
3. After the film put the film firmly with tape posted on the receipt paper tube.


Sealing procedures (panel operating instructions):
1. Power, turn the power switch, indicator lights, the thermostat is set to a predetermined temperature, when the green heating indicator light. When the hot plate reaches a predetermined temperature, the red indicator light is constant (sealing machine at work, electric heating and insulation means constantly alternating states, so green and red lights are constantly alternating, this is normal).
2. The plastic cups were placed in the lower mold slide, slide his hands pushed into the die to determine the location, after touching the limit switch, the module automatically after receiving the signal under the pressure seal, reset automatically rise, touched on travel switch on mold motor stops. film motor begins to turn, turned a predetermined length film by electric eye controlling the motor stops automatically.
3. After the film must be the motor rotation, only pulled lower mold slide the plastic cup into the lower mold slide pushed into the next cycle begins.



Precautions:
1, take a good ground to ensure safe use of electricity.
2, when the machine fails, you should turn off the power, resume normal temperature before troubleshooting.
3, the use of the process must not hand into the upper and lower mold, so as not to crush or burns.
4, carrying cup push die movement, the die must be carried out at the highest point of stop motion.
5, template-carrying cup to a later innermost allowed rebound, or upper and lower mold will be damaged.
6, the working voltage must be maintained at 220V ± 5%.

Company Profile


Guangzhou ETON Electromechanical Co., Ltd is a leading company that mainly focuses on producing high quality electromechanical products, especialy for Food machinery and Packing machinery.

Our company has a large number of management and technology staff who have high degree and high technical post title, after many years' training, our company has won a working group with good technology and high job diathesis.

Our company has heavy oil hydraulic press machine  of 500 tons and a series of advanced manufacturing equipment and exact detectingequipment, the area of the workshop is over 40000 square meter.

In order to meet the world market demand, our company passed the international quality inspection of ISO 9001:2000 in 2003, many products get the “CE” certificate awarded by the Europe Alliance and the CTA certificate awarded by China Products Quality Monitoring & Inspection Alliance, also get the reputation of “High Grade supplier of China”.

With all the staff's long time persistent efforts, our product quality keeps continuously improving, we got 15 patents for many products early or late, the pertinent country departments conferred us “China Famous Products” , “China Famous Brand” honorable titles, we got the “An enterprise of the AAA Quality & Credit of China” for the late three years. Our company also is one member of “China consumer right vindicating league” at the same time.

Our company has independent import & export licence, the products can be sold to 48 countries overseas, such as Europe, South America, North America, Oceania, Middle east, Africa, 10 countries of East Alliance, and our products are all warmly welcomed.
