•   ZTM-H Series Servo Drive Film Defect Inspection Machine

ZTM-H Series Servo Drive Film Defect Inspection Machine

When innspection is done, the computer will show all the defect details and photos

Product Details

Quick Details

Description

Characteristics:

1)Automatic mode:

When a defect is detected, the machine reduces its speed until it sops rewinding, then the film is automatically rewind back and the defect area stops over an inspection plate for visual examination.

2)Semi-Automatic mode:

When a defect is defected, the machine does not reduce speed, it will save the data with photos in the computer and keep inspection after rewinding is finished. When innspection is done, the computer will show all the defect details and photos, when click the defect through by the computer, the machine auto rewind back and defect area stops over an inspection plate for visual examination.

Technical parameter:

Jumbo roll width: 1000-1600mm

Diameter of roll: 600-1000mm

Diameter of rewind: 600-1000mm

Mechanical speed: 300m/min

Total power: 18-25KW

Weight: 2500-3500kgs

Overall dimension: 3200mmx3500mmx2000mm



  ZTM-H Series Servo Drive Film Defect Inspection Machine

Company Profile

Ruian Zhongtai Packaging Machinery Factory is located in Ruian, Wenzhou, Zhejiang Province, China.
We are one of the professional factory which is specialized in Slitting Rewinding Machine, PVC Sealing Machine etc.
We have more than 10 years's experience in this machinery industry, and mostly for export business.
Sincerely hope to cooperate with you.

Ruian Zhongtai Packaging Machinery Factory
